Re: Can Am BBC
|
Re: Can Am BBC
Here is all the info that I have: casting #326711 Reynolds 68/69 Can Am block 4.44" bore with steel liners
|
Re: Can Am BBC
<div class="ubbcode-block"><div class="ubbcode-header">Originally Posted By: 69SSZL1</div><div class="ubbcode-body">Here is all the info that I have: casting #326711 Reynolds 68/69 Can Am block 4.44" bore with steel liners </div></div>
Im sorry but thats my Block. not the last Picture. I wanted to show what Pictures we need to see |
Can Am BBC
'
Da' Grump used one or more Can-Am block(s)! If any help, here's a few block casting #'s and related info I've posted here before. Anyone please feel free to add missing/more info also clarify and/or correct any mistakes. [img]<<GRAEMLIN_URL>>/beers.gif[/img] ~ Pete - Can-Am blocks 68/69 - Reynolds # 0-294550 = Linerless? # 0-321270 = Linerless? # O-326711 = 4.44" bore with steel liners (427 ci) Can-Am blocks 70/71 - Reynolds? # O-399204 = 4.5" bore and steel liners (509 ci) # O-495102 = 4.5" bore and no liners ZL-1 Factory blocks - 1969 - Winters # 3946052 (No 'O') 427 ci. ZL-1 Factory blocks - 1997 & up # 3946053 (No 'O') 427 ci. # 3992038 (O?) * may be 4.44" bore w/ Liners - era?. # ? - Yenko - Casting has YENKO # ? - Yenko - Casting has Y E N K O # ? - Yenko - Casting has Yenko Crest Logo Note - The #3946502 quoted on Guinn's Engineering site is actually # 3946052 as shown in their pics. - |
Re: Can Am BBC
I can update that list.
Can-Am blocks 68/69 - Winters # 0-294550 = 4.250" bore with steel liners (427 ci) # 0-321270 = 4.440" bore with steel liners no fuel pump boss (430, 465 ci) # O-326711 = 4.440" bore with steel liners (430, 465 ci) # 3946052 = 4.440" bore with steel liners (430, 465 ci) # 3946053 = 4.440" bore with steel liners (430, 465 ci) Can-Am blocks 70/71 - Reynolds? # O-399204 = 4.5" bore and steel liners (509 ci) # O-495102 = 4.5" bore and no liners ZL-1 Factory blocks - 1969 - Winters # 3946052 (No 'O') 427 ci. # 3946053 427 ci ZL-1 Factory blocks - 1997 & up # 3946053 (No 'O') 427 ci. # 3992038 (O?) * may be 4.44" bore w/ Liners - era?. # 3946052 Yenko Casting LC 427 # 3946053 Yenko - Casting has YENKO # 3946053 Yenko - Casting has Y E N K O # 394605Y Yenko - Casting has Yenko Crest Logo |
Re: Can Am BBC
Can-Am blocks 68/69 - Winters
# 0-294550 = 4.250" bore with steel liners (427 ci) # 0-321270 = 4.440" bore with steel liners no fuel pump boss (430, 465 ci) # 0-326711 = 4.440" bore with steel liners (430, 465 ci) # 3946052 = 4.440" bore with steel liners (430, 465 ci) # 3946053 = 4.440" bore with steel liners (430, 465 ci) Can-Am Block 70 Winters # 3946052 = 4.440" bore with steel liners (494 ci) # 3946053 = 4.440" bore with steel liners (494 ci) Can-Am blocks 70/71 - Reynolds # O-399204 = 4.5" bore and steel liners (509 ci) # O-495102 = 4.5" bore and no liners ZL-1 Factory blocks - 1969 - Winters # 3946052 427 ci. # 3946053 427 ci ZL-1 Factory blocks - 1997 & up # 3946053 427 ci. # 3992038 may be 4.44" bore w/ Liners - era?. # 3946052 Yenko Casting LC 427 # 3946053 Yenko - Casting has YENKO # 3946053 Yenko - Casting has Y E N K O # 394605Y Yenko - Casting has Yenko Crest Logo |
Re: Can Am BBC
I have internal engineering documents dated Feb 29, 1968 showing the following aluminum 427's equipped with sleeves:
19950-17-A (first development engine, installed in Corvette 78027 for F.I. development) 19950-17-J (Laguna Seca race and Riverside Practice, #3, #4, #6 resleeved and machined) 19950-17-K (ran LeMans for 14 hrs, approx 1000 miles, showed gasket burning on #1 cyl) Not sure how these numbers correspond to the ones listed above, but I believe these were development blocks. Mike |
Re: Can Am BBC
I will take some pictures tomorrow and post them. Guinn was convinced this was one of the early experimental blocks because of the crude casting and no numbers anywhere. Not quite sure what happened to him. Also, the fact that it was a dry sump block with the fuel pump boss and liners. Will post pics tomorrow!
|
Re: Can Am BBC
Can-Am blocks 68/69 - Winters
# 0-294550 = 4.250" bore with steel liners Experimental Prototype 67-68 Dry sump (427 ci) # 0-321270 = 4.440" bore with steel liners Experimental Prototype 68 no boss for mechanical fuel pump(430, 465 ci) # 0-326711 = 4.440" bore with steel liners Experimental Prototype 68 (430, 465 ci) # 3946052 = 4.440" bore with steel liners (430, 465 ci) # 3946053 = 4.440" bore with steel liners (430, 465 ci) Can-Am Block 70 Winters # 3946052 = 4.440" bore with steel liners (494 ci) # 3946053 = 4.440" bore with steel liners (494 ci) Can-Am blocks 70/71 - Reynolds # O-399204 = 4.5" bore and steel liners (509 ci) # O-495102 = 4.5" bore and no liners ZL-1 Factory blocks - 1969 - Winters # 3946052 427 ci. # 3946053 427 ci ZL-1 Factory blocks - 1997 & up # 3946053 427 ci. # 3992038 may be 4.44" bore w/ Liners - era?. # 3946052 Yenko Casting LC 427 # 3946053 Yenko - Casting has YENKO # 3946053 Yenko - Casting has Y E N K O # 394605Y Yenko - Casting has Yenko Crest Logo |
Re: Can Am BBC
|
